Truck 1080P Rear View Backup Camera Waterproof IP68 Night Vision Recorder Ensuring Safer Vehicle Management Reversing Monitoring
- Overview
- Recommended Products
Pruduct Description
🚛 Heavy-Duty Rear View Camera with IR Night Vision for Commercial Vehicles
Resolution: 1080P AHD | IR Distance: 15M | Waterproof Rating: IP68
This rear-mounted vehicle camera is built for tough environments and real-time safety.Designed for trucks, trailers, and fleet vehicles, it offers crisp 1080P imaging, 15-meter infrared night vision, and a rugged IP68 waterproof housing. Whether reversing or recording,this camera helps reduce accidents and provides reliable rear visibility.
💡 Why Drivers & Fleet Managers Prefer This Camera?💡
See More. Reverse Safer. Drive Smarter.
✅ 720P / 1080P AHD or IP Output
Supports both analog and network systems for flexible integration.
✅ 15M Infrared Night Vision
18pcs IR LEDs provide clear rear footage in low light or darkness.
✅ IP68 Waterproof Housing
Fully sealed against rain, mud, and pressure washing environments.
18pcs IR LEDs provide clear rear footage in low light or darkness.
✅ IP68 Waterproof Housing
Fully sealed against rain, mud, and pressure washing environments.
✅ 2.8mm Wide Angle Lens
Covers a broad rear field to reduce blind spots and increase awareness.
✅ Shockproof and Loose-Proof Mount Design
Withstands road vibration and rough conditions.
✅ Adjustable Sun Visor Shield
Prevents glare and protects lens from dust or direct sunlight.
✅ Auto White Balance & Backlight Compensation
Delivers consistent image quality in varied lighting.
Covers a broad rear field to reduce blind spots and increase awareness.
✅ Shockproof and Loose-Proof Mount Design
Withstands road vibration and rough conditions.
✅ Adjustable Sun Visor Shield
Prevents glare and protects lens from dust or direct sunlight.
✅ Auto White Balance & Backlight Compensation
Delivers consistent image quality in varied lighting.
💡 Application Scenarios 💡
1.Truck & trailer rear monitoring during reversing or loading
2.Bus and van rear blind spot visualization
3.Commercial vehicle fleet video recording for insurance protection
4.Outdoor parking assistance for large vehicles
5.Evidence capture for traffic or collision incidents
Product Paramenters
Product Name |
Vehicle Rear View Camera |
Model |
MX-AHDH-803 |
Project |
Parameter |
Sensor |
1/2.9" Aptina 0130 + Nextchip2431 |
Signal system |
PAL/NTSC |
Resolution |
1080P AHD |
Lens |
2.8mm wide angle |
IR Distance |
15 meters |
IR LEDs |
18pcs φ5 IR LED,850nm |
Minimum Illumination |
0Lux |
Waterproof Rating |
IP68 |
Operating Temp |
-20°C ~ +60°C |
Power Supply |
DC12V±10% |
Power Consumption |
<3W |
Video Output |
1.0Vp-p,75Ω |
Size |
80*60*67.5mm |
Details Images
Customer Photos
Our Company
FAQ
Q1: Can this camera work independently without MDVR?
A1: No, it needs to be connected to MDVR to work together.
Q2: Does it support audio?
A2: Yes, it support.
Q3: What lens options are available?
A3: Standard lens is 2.8mm; 8mm lens can be customized upon request.
Q4: Can it be used in extreme temperatures?
A4: Yes, it works reliably from -20°C to +70°C, suitable for most environments.
Q5: Do you provide MDVR systems together?
A5: Yes, we offer complete MDVR + camera + platformsolutions for fleet management and video surveillance.
Q6: Do you offer OEM or customization services?
A6:Yes. We support ODM &OEM.
Q7: What is your warranty policy?
A7:Standard 12-month warranty.
Q8: Can this system integrate with fleet management platforms?
A8:Yes,we support CMS platforms or custom server integration. Contact us for compatible solutions.
